Bosch Dishwasher Lights Meaning & Blinking Codes

Most Bosch dishwasher lights are status indicators, not faults: a lit Add Rinse Aid light means the dispenser is low, a lit Sanitize light means the sanitation requirements were met, and a flashing last-used cycle light means the machine is waiting for you to pick a cycle. Real faults usually appear as an E-code on the display (for example E15 for a leak or E22 for a blocked filter), and older models without a display may signal faults through a blink pattern that your manual decodes. Codes and light layouts vary by model, so check your own manual. If a code keeps returning after a reset, call a technician.

Read More: Can Pyrex Go in the Dishwasher? Rules by Piece Type

Normal Lights and What They Mean

The table below comes from one Bosch dishwasher Use and Care Manual, which doesn’t say which models it covers, so your panel may have different lights.

Light or displayMeaningSource section
Add Rinse AidRinse aid is low. It goes off shortly after the door closes once you refill itAdding Detergent and Rinse Aid
Last-selected cycle LED, flashingThe machine is on and waiting for you to choose a cycle (normal)Operating the Dishwasher
Sanitize LEDLights when the sanitation requirements for the cycle have been met. Available only with Heavy, Auto and NormalWash Cycle Options
InfoLight (floor light), model dependentProjects light onto the floor to show the unit is running. Not visible if the dishwasher is at eye levelInfoLight
CL on the displayChild lock is activeChild Lock

Source: Bosch dishwasher Use and Care Manual (PDF). That manual has no Clean, Dry, Wash, Salt, or Delay lights and lists no E-number codes. Other Bosch models differ.

Display Codes That Are Settings, Not Errors

Don’t mistake these for faults. From the same manual:

DisplayMeaning
h:01 to h:24Delay start in one-hour steps (h:00 cancels it)
0:01Shown while cancelling a cycle (hold Start about 3 seconds)
d:00 / d:01Intensive drying off / on
b:00 to b:03Cycle-completion tone from off to loudest
r:00 to r:06Rinse aid amount (r:00 turns the dispenser off)
P:00 to P:02Auto Power Off: never, 1 minute,e or 120 minutes
1:01 / 1:00InfoLight on / off
CLChild lock on

A reader on How To Fix It reports that h:01 means a 1-hour delayed start, not an error. That’s a reader’s comment, but it matches the manual.

Common Bosch Error Codes

Bosch’s manual that I read lists none, so these come from repair sites. They vary by model, and the sites disagree on some codes. Fred’s Appliance says its codes vary by model, so check your manual.

CodeWhat it usually meansTypical first stepSource
E09Heating circuit fault (heating element, heat pump or relay)Check element continuity or call a technicianHow To Fix It, Fred’s, ServiceWorks
E15Water in the base tray (leak)Check hoses and seals, drain the tray, unplug the unitHow To Fix It, Fred’s, ServiceWorks
E22Blocked filterRemove and clean the sump filterHow To Fix It, ServiceWorks
E24Drain blocked (hose or filter)Check the drain hose and filterHow To Fix It, ServiceWorks
E25Drain pump blocked or failingOpen the pump cover, remove debris, check the impellerHow To Fix It, ServiceWorks
E08Water level dropped during a cycleCheck for overturned bowls, then for leaksHow To Fix It, Fred’s
E14Flow sensor doesn’t detect incoming waterCheck supply, then the sensorHow To Fix It, Fred’s
E27Under voltageUnplug for about five minutes, then call a technician if it returns (Fred’s)How To Fix It, Fred’s

Codes the sources disagree on

CodeHow To Fix ItFred’s Appliance
E01Heat pump motor circuit fault; possible control board failurePump control circuit or thermistor problem; usually the control board
E02Heater relay fault; main control boardHeater relay or thermistor; follow the E01 steps
E03Auxiliary heater relay faultAuxiliary heater relay, or the unit isn’t filling
E19Dispenser solenoid faultHeating issue
E20Circulating pump faultHeating issue
E21Circulating pump blockageHeating issue
E23Drain pump electrical faultDrainage issue, a defective pump, ora  clogged hose

How To Fix It also has inconsistencies of its own. For example, its table calls E4 “heater electronics” while its text calls it a flow sensor, and the page doesn’t explain this. Treat any code on this list as a lead, not a diagnosis, and check your model’s manual or a technician.

What About Blinking Lights With No Display?

  • ServiceWorks says older models show codes through a blinking light pattern instead of a display, and that the owner’s manual includes a chart matching each pattern to its problem. It doesn’t list the patterns.
  • How To Fix It notes that during test mode, the lights above the buttons flash to confirm entry. That’s a test mode, not a fault.
  • A reader on the same site reports a flashing “Refill Rinse Agent” light and suggests a stuck float switch, a control board glitch,o r a dirty or blocked rinse aid sensor. That’s one reader’s comment.
  • The Bosch manual I read describes only one flashing behavior (the last-selected cycle LED), which is normal.

I couldn’t find a reliable, model-independent chart for blink patterns. Your manual (search your model number, E-Nr, on the rating plate) is the right source. If you’ve lost it, a technician or Bosch support can decode the pattern.

How to Reset a Bosch Dishwasher

  1. Standard reset. Turn the dishwasher off, unplug it or flip the breaker for about 30 seconds (How To Fix It), then restart. ServiceWorks suggests waiting five minutes if a Start-button reset doesn’t work.
  2. Start-button reset. ServiceWorks says to hold Start for a few seconds until the display resets, and that some models need two buttons together. It doesn’t detail the combinations.
  3. H24 service code. How To Fix It says to unplug, then hold Start for about 10 seconds after power returns.

A reset clears temporary faults only. If the code comes back, the cause still needs fixing (ServiceWorks).

Quick Troubleshooting for Light Problems

From the Bosch manual’s Troubleshooting Guide:

ProblemWhat to try
Add Rinse Aid light stays onRefill the dispenser, don’t overfill, close the lid until it clicks, wipe up spills. The light should go out shortly after you shut the door
Display doesn’t lightCheck the fuse or breaker and make sure the door is fully latched. On models with controls on top of the door, the display lights only when the door is open
“Check water supply” lights upConfirm the supply valve is open and the line isn’t kinked or clogged. Also check for an unfinished cycle, active delay start, or household water being off
Won’t startMake sure the door latches, power wasn’t interrupted,d and a cycle was selected before closing
Buttons activate on their ownWater, grease, or food on the panel, or wiping it, can trigger touch buttons. Dry the panel and never pour water on the controls.

When to Call a Technician

  • The code returns after a reset. ServiceWorks says a reset clears only temporary faults.
  • Control board, heater,r or relay codes. Fred’s Appliance names E01, E02, E05, E06 and E09 as codes that typically need a technician, since testing a control board requires specialist knowledge.
  • Repeated leaks (E15). ServiceWorks says repeated leaks suggest an internal failure.
  • The manual’s own advice. For a fault you can’t resolve with its Troubleshooting Guide, it says not to repair the unit yourself and to call 1-800-944-2904 or an authorized service center.

Fred’s Appliance and ServiceWorks are a repair company and a content site for service businesses, so their calls to book service are partly marketing. The advice is consistent with Bosch’s own manual.

Frequently Asked Questions

What does the rinse aid light mean on a Bosch dishwasher?

The rinse aid dispenser is low. Refill it, close the lid until it clicks, and the light goes out shortly after the door closes.

What does the Sanitize light mean?

It lights when the cycle meets the sanitation requirements, per the manual. Sanitize is available only with Heavy, Auto, and Normal.

Why is my Bosch dishwasher light flashing?

A flashing last-selected cycle light is normal, since it shows the machine is waiting for you to choose a cycle. Other flashing patterns depend on your model, so check your manual.

What does h:01 mean on a Bosch dishwasher?

A one-hour delay start, not an error. h:00 cancels it.

What does CL mean?

Child lock is active. On models that have it, hold the Child Lock button for about 3 seconds until CL disappears.

What does E15 mean?

Water in the base tray. Check for leaks and slipped hoses, and unplug the unit. Three of the sources agree on this one.

What does E22 mean?

A blocked filter. Remove it and clean it in warm water.

What do E24 and E25 mean?

Drainage problems. According to How To Fix It, E24 points to a blocked hose or filter, and E25 points to the drain pump.

What does E09 mean?

A heating circuit fault. The element, heat pump, or relay may have failed, and a technician is often needed.

Conclusion

Most Bosch dishwasher lights tell you something routine: the rinse aid is low, the sanitize requirements were met, or the machine is waiting for a cycle choice. A real fault shows as an E-code, and E15, E22, E24, and E25 are the ones most sources agree on, and homeowners can often start on their own. Because codes and blink patterns vary by model and the sources disagree on several, check your manual first, try a reset, and call a technician if the code returns or involves the heater, relay, or control board.
